API standards are critical for ensuring the quality and safety of drill pipe inspections. By following API standards, drilling contractors can be sure that their inspection procedures meet industry best practices.
In this blog post, we'll take a closer look at some of the most important API standards for drill pipe inspections.
What are API Standards for Drill Pipe Inspections?
The American Petroleum Institute (API) has published several specifications for drilling pipe used in drilling oil and natural gas wells.
Three of these are API 5A, RP 7G-2, and 5DP. These documents establish minimum requirements that should be considered part of an effective management system to ensure that customers receive products that meet their needs. They provide guidance on the materials, dimensions, tolerances, strength properties, tests, and inspections typically required by different applications found in the industry today.
From a driller's perspective, it will ultimately help ensure that the drill pipe you are using is still fit for purpose and could potentially reduce impact to operational time as a result of an inspection failure. Once these standards are implemented, any drill pipe that is found to be within specification will need to be re-certified if it is removed from the hole.
Why Are Drill Pipes Inspected?
Drill pipe inspections are critical to maintaining the safety and functionality of oil and natural gas wells. Proper inspection helps prevent potentially hazardous situations and ensures the structural integrity of the well.
-
Safety Concerns: Just as improperly installed gas lines or appliances can lead to carbon monoxide leaks, fires, or other deadly outcomes, poorly installed oil and natural gas wells can result in fires, explosions, or blowouts with potentially fatal consequences.
-
Well Construction: Oil and natural gas wells are constructed using threaded connections secured with nuts, bolts, or torqued joints. Drilling fluid circulates through the drill string, and formations are fractured by pumping small explosive charges down the casing. This process involves fracturing fluids containing water, chemicals, and proppants like sand, ceramic beads, or sintered bauxite to keep fractures open during production.
-
Post-Production Requirements: Once the well begins producing, the drill pipe and other components must be removed from the well bore. This prevents damage to production equipment and reduces risks of safety hazards, such as fires and explosions.
What are the consequences of not inspecting drill pipes?
The consequences could range from faulty equipment and/or poor production rates to catastrophic blowouts. The time when the most wear occurs on drill pipe is during its use for fracturing operations. If a faulty pipe is used, it can fail in very little time after installation due to high stresses at the fracture face where the pressure of the fluid pumped down through the well bore exceeds 15,000 psi (normal operating pressures range from 5000 to 10,000 psi).
Because this happens so rapidly and because there are so many joints typically involved in a fracturing operation, it's easy to see that even one failed joint could cause significant damage if not safety hazards. Bear in mind that these extremely high pressures occur in formations that contain gas and/or oil under tremendous pressure beneath thousands or sometimes millions of tons of rock. The results of a fracture going into a gas or oil reservoir could be catastrophic.
What does API do?
Where appropriate, API develops standards that promote public safety and environmental protection. Standards are based on consensus among industry leaders and provide a means for companies to show that they have met the criteria necessary to be in compliance with the standard.
The development of standards is often driven by real-world evidence brought forth by member companies that have identified problems or concerns about their equipment, facilities, or practices that must be addressed by all members throughout the industry. This helps address inconsistencies where one company's interpretation of requirements differs dramatically from another company's interpretation even though both customers may think they are covered by the same requirement because neither realized interpretations varied so widely.
Because of the diversity in the type and mission of oil field companies, there are three different categories of standards:
-
Process Standards including well construction, completion, testing, workover & plugging
-
Management Standards that address planning, health, safety & environmental issues
-
Quality Assurance Standards for manufacturing to ensure quality products are being produced by high-quality systems
What is API 5A?
In 1999, API developed standard 5A with consensus from industry leaders to establish a common set of equipment inspection requirements for drill pipe.
Why was this needed?
The development of a drill pipe inspection standard arose from a series of significant incidents in the oilfield industry. These events highlighted the need for a unified approach to identifying and addressing flaws in drill pipes before they could lead to catastrophic failures.
-
The Enoch Point Field Blowout: In February 1996, a blowout at the Enoch Point Field in California resulted in an uncontrolled release of oil, causing severe damage to wildlife, vegetation, and property. The cause was traced to a pre-existing fracture in a drill pipe that routine inspections had failed to detect.
-
Additional Incidents: Within ten years of the blowout, two other incidents occurred at the same field involving undetected fractures in drill pipes. While these fractures did not escalate to well control situations, they underscored the potential for catastrophic consequences if left unaddressed.
-
Development of API 5A: These incidents led to the creation of API 5A, a standard inspection guideline aimed at detecting changes in pipe dimensions. The standard includes minimum size requirements that can be measured using the API 5A inspection gauge, ensuring consistency and accuracy across the industry.
Who does API 5A apply to?
All drill pipe used in oil and gas wells must comply with the requirements and since it is common practice that drill pipe is exchanged between various companies, there are no exclusions for single well operators even if the drill pipe is installed by the customer. Most well construction companies also specialize in API 5A inspections for their customers to help ensure compliance with API standards.
What is API RP 7G-2?
API RP 7G-2 specifies the required inspection for each level of inspection, procedures for the inspection, and testing of used drill stem elements. For the purposes of this standard, drill stem elements include drill pipe body, tool joints, rotary shouldered connections, drill collar, heavy-weight drill pipe (HWDP), and the ends of drill stem elements that make up with them.
This standard specifies the required inspection for each degree of inspection, as well as inspection and testing procedures for used drill stem components. Drill stem components are defined in this standard as including drill pipe bodies, tool joints, rotary shouldered connections, drill collars, heavy-weight drill pipe (HWDP), and the ends of drill stem components that make up with them.
Why follow API RP 7G-2 for inspections?
The API standard for used drill stem elements specifies the standards for each degree of inspection and testing, as well as procedures and requirements.
Inspectors and operators may sleep well at night knowing that following the API Recommended Practice will guarantee that they are maintaining high-quality drill pipe and will not encounter non-productive time (NPT) as a result of drill pipe problems.
How does API RP 7G-2 standard apply to oil and gas well drilling?
This standard applies to all drill pipe used in oil and gas wells within the United States, wherever it is made, shipped or used in service.
The requirement for a minimum diameter for work-performing drill pipe is not intended to apply to drill pipe used as casing or liner, as such components must meet the minimum dimensions as stated in API Spec 8C.
What is API 5DP?
API 5DP provides guidance for the inspection of inside diameters (IDs) and lengths of drill pipe. For API 5A, only the outside dimensions are measured; ID measurements are not required to be taken on straight threaded connections. Under API RP 7G-2, both inside and outside dimensions must be measured at each level of inspection.
What are API 5DP Inspection Levels?
API 5DP inspection levels are a series of rigorous steps designed to ensure the quality and integrity of drill pipes. Each level has specific measurement requirements to evaluate pipe thickness and dimensions.
-
Level 1: The drill pipe must pass all measurements at or above the minimum wall thickness using a no-go gauge.
-
Level 2: Both inside and outside measurements are taken, with thin wall sections (≤ 0.035 inch) measured using an external micrometer.
-
Level 3: All sections of the drill pipe are inspected, with exterior dimensions measured using an inside micrometer and interior dimensions verified using a no-go gauge.
-
Level 4: ID measurements must pass a no-go gauge, while exterior dimensions are measured using an outside micrometer.
When must API 5DP be implemented?
API 5DP went into effect on February 1, 2009 for all drill pipe shipped from the manufacturer to the job site or used in service after this date. For existing fleets of drill pipe, API RP 7G-2 is to be implemented no later than July 1, 2009.
There is an exception to this requirement: API RP 7G-2 does not need to be followed for drill pipe used as liner or casing components. These connections must meet the minimum requirements as stated in API Spec 8C.
Why follow API 5DP?
API 5DP is a valuable tool for improving the quality of drill pipe and avoiding NPT. It provides a consistent method for measuring ID and thickness, thus eliminating variability; it also requires that all measurements be taken on each standard level of inspection.
Other API Standards for Drill Pipe
To define the delivery requirements for drill pipe production, there are several API standards in place. These API documents will show you what the new form of drill stem components should look like:
- API Spec 7-1: Specification for rotary drill stem elements
- API RP 7-2: Specification for threading and gauging of rotary shouldered thread connections
- API Spec 5B: Threading, gauging and inspection of casing, tubing, and line pipe threads
- API RP 5B1: Gauging and inspection of casing, tubing, and line pipe threads
Superior Performance: Setting the Benchmark with API Standards for Drill Pipe Inspections
API standards for drill pipe inspections are the backbone of safety, efficiency, and quality in the oil and gas industry. These guidelines, such as API 5A, RP 7G-2, and 5DP, ensure that drill pipes meet stringent requirements for materials, dimensions, and inspections, ultimately protecting operations from catastrophic failures and costly downtime.
By adhering to these standards, companies can safeguard both their equipment and personnel, all while maintaining environmental and operational integrity. At Superior Performance, our team embraces API standards as not just a compliance measure—but a commitment to excellence and the long-term success of drilling operations. Contact us to get more information about our tool rental offerings!
About Superior Performance
Superior Performance is a leader in the premium tubular business. Our extensive knowledge of rig operations allows us to prevent problems and offer innovative products to avoid downtime at the rig site. Our offerings include: Multi-Service Provider, Rental Tools, Power Equipment. Other offerings include: thread inspection services, casing I.D caliper and Laser Tally.
At Superior Performance, our team provides drilling contractors and operators with a wide range of construction services to cover most work scopes associated with rig/drilling packages and upgrades, refurbishment, and repair.
