Drilling and blasting is a method used for excavation throughout the world. This process can be used in all types of rocks and its cost is lower than other mechanical methods like Tunnel Boring Machines (TBM).
But how exactly does this process work and what does it involve?
Let's dive into everything you need to know about drilling and blasting.
- What is drilling and blasting?
- Why is drilling and blasting important?
- What does the process of drilling and blasting entail?
- What are the benefits of drilling and blasting ?
- What kind of engineers are involved in the process of drilling and blasting?
What is drilling and blasting?
This is a process followed to break rock for excavation purposes, via controlled use of explosives and other methods such as gas pressure blasting pyrotechnics. Drilling and blasting is practiced most often in mining, quarrying, and civil engineering projects.
The result of rock blasting is often known as a rock-cut.
Why is drilling and blasting important?
Drilling and blasting can significantly affect the productivity and costs of downstream operations, including loading, hauling, crushing and screening, and product yield.
Drilling and blasting is also a very effective process when compared with bored tunneling by TBM, since blasting generally results in higher duration of vibration levels. The excavation rate is also less than TBM (usually 3 to 5m a day).
Drilling and blasting offer the greatest opportunity to optimize quarry operations and control costs.
What does the process of drilling and blasting entail?
The drilling and blasting technique consists of the drilling of boreholes in the rock, the placing of explosives and blasting to properly fragment the work section.
The typical cycle of excavation by blasting is performed in the following steps:
1. Drilling
As the word suggest, this step involves drilling blast holes and loading them with explosives.
During this step, jumbo machines are used to drill the holes where the explosives will be charged.
Jumbo machines are have three drilling arms and an operator tower. These tools run by electric cable; a hose brings water to pneumatic drills allowing for the drill bits both hammer and rotate. These drill holes can be between 2.4-3.6 metres long.
2. Explosive Charging
The boreholes are filled with explosives, detonators are attached to the explosive devices and the individual explosive devices are connected to one another. Some of the explosive devices commonly used include dynamites, hydro-gels, emulsions and ANFO (Ammonium Nitrate Fuel Oil).
The process of charging equipment is typically mechanized for safety purposes. Charging explosives this way ensure that explosives are safely charged into the boreholes.
In terms of safety, civil and structural engineers can now monitor hazardous areas remotely thanks to remote sensing technology.
3. Blasting
The boreholes are blasted in a proper sequence, from the center outward, one after the other.
The process of blasting is typically triggered sequentially to ensure optimal fragmentation of the rock is achieved and also to ensure that vibrations produce do not affect the integrity of its surroundings.
4. Ventilation
Explosions create clouds of dust that then mix with the combustion gases, which make ventilation a vital step.
Ventilation can be accomplished by using so-called air-ducting systems, long steel or plastic pipes, often are attached to the roof of the tunnel and blow fresh air onto the working face. These tools allow for localized excess pressure to ventilate.
5. Mucking & Scaling
It is important for rubble to be removed and for the tunnel's surface to be reinforced.
Removal of the blasted rock (mucking) entails the following steps steps: loading and hauling the muck, and final transport out of the worksite. Special machinery designed for this process (dump trucks and shovels) are used to complete this process.
During this step crown and walls are scaled down to remove loosened pieces of rock.
6. Installing initial ground support.
As a tunnel progresses it's ceiling and side walls need to be supported in order to prevent rock from falling into the excavation. Methods to accomplish rock support may vary but typical rock support systems include:
- Rock bolts or rock dowels
- Shotcrete
- Ribs or mining arches and lagging
- Cable bolts
- In-situ concrete
Depending on the site’s characteristics, the tunel support can be either light or heavy-duty, and combines shotcrete alongside bolts and steel mesh.
What are the benefits of drilling and blasting ?
The main benefits of drilling and blasting technology are that it is very cost-effective, offers great versatility, and is suitable for most ground conditions.
It can also be used to create openings with a more predictable shape than those made by mechanical excavation systems.
Moreover, due to the short cycle times, drilling and blasting can be used for large earth moving projects, such as the construction of underground tunnels and highways.
Finally, blasting technology can also be used to break up rock into smaller pieces that can then be moved, crushed or milled. This makes it a great tool for mining industries.
What kind of engineers are involved in the process of drilling and blasting?
Drilling and blasting requires the expertise of civil and structural engineers, as well as mining engineers. Civil and structural engineers are responsible for designing the layout and ensuring safety protocols, while mining engineers help optimize the process by using sensors to measure vibrations, study rock characteristics, program explosives detonations, etc.
In addition to this core team of engineers, a number of other professionals are also involved, such as explosives technicians, drillers, and mucking and scaling personnel. All these experts have the necessary knowledge and experience to ensure that the excavation process is completed properly and safely.
